Product details
The Orbea Orca M30 is a lightweight road bike built for performance and precision. Featuring the Shimano 105 12-speed groupset, this bike ensures flawless shifts every time. The Orca carbon OMR frame is designed for instant acceleration, responsive handling, and vibration absorption, making it ideal for both climbs and long rides. Its clever frame design reduces vibrations, saving energy and offering comfort without compromising stiffness.
With a 32mm tyre clearance and tubeless-ready wheels, the Orca M30 maximises traction and ride compliance. The carbon 27.2mm seatpost adds to the bike's comfort while maintaining its lightweight nature. Orbea’s timeless design, backed by a lifetime warranty, combines sleek style with cutting-edge technology, making the Orca M30 the perfect choice for cyclists seeking speed, control, and endurance.
Specifications
| Frame |
Orbea Orca carbon OMR 2024, monocoque construction, HS 1,5", BB 386mm, powermeter compatible, Rear Thru Axle 12x142mm, thread M12x2 P1, internal cable routing. |
| Fork |
Orbea Orca OMR ICR 2024, full carbon, 1-1/8" - 1.5" tapered head tube, Thru axle 12x100mm, thread M12x2 P1. |
| Headset |
FSA 1-1/2" Integrated Aluminium Cup |
| Crankset |
Shimano 105 R7100 34x50t |
| Cassette |
Shimano 105 R7100 11-34t 12-Speed |
| Rear Derailleur |
Shimano 105 R7100 |
| Front Derailleur |
Shimano 105 R7100 |
| Handlebar |
OC Road Performance RP31-R, Rise 15, Reach 70, Drop 125 |
| Stem |
OC Road Performance RP22, -5º |
| Brakes |
Shimano R7170 Hydraulic Disc |
| Wheels |
Alloy, Tubeless, 700c, 19c, 28H |
| Tyres |
Vittoria Zafiro V Rigid bead 700x28c |
| Front Wheel Axle |
Orbea Thru Axle 12x100mm M12x2 P1 Hollow |
| Rear Wheel Axle |
Orbea Thru Axle 12x142mm M12x2 P1 Hollow |
| Seatpost |
SP 0.2 Carbon, 27.2mm, Setback 20 |
| Size |
Height (cm) |
Height (in) |
| 47 |
155-160 |
5'1" - 5'3" |
| 49 |
160-166 |
5'3" - 5'5" |
| 51 |
167-172 |
5'6" - 5'8" |
| 53 |
173-179 |
5'8" - 5'10" |
| 55 |
180-185 |
5'11" - 6'1" |
| 57 |
186-191 |
6'1" - 6'3" |
| 60 |
192-207 |
6'4" - 6'9" |
*Estimated measurements
Here is the geometry chart for the Orbea Orca M30:
| Size |
47 |
49 |
51 |
53 |
55 |
57 |
60 |
| 1. Seat Tube (C-T) |
440 |
460 |
480 |
500 |
520 |
540 |
570 |
| 2. Top Tube (EFF) |
510.3 |
522.7 |
535.9 |
548.5 |
560.4 |
576.1 |
590 |
| 3. Head Tube |
110.5 |
118.2 |
134.6 |
152.9 |
173.1 |
191.2 |
218.3 |
| 4. Chainstay |
408 |
408 |
408 |
408 |
408 |
408 |
408 |
| 5. BB Height |
268.5 |
268.5 |
268.5 |
270.5 |
270.5 |
270.5 |
270.5 |
| 6. BB Drop |
72 |
72 |
72 |
70 |
70 |
70 |
70 |
| 7. Wheelbase |
971.8 |
975.4 |
980 |
981.2 |
991.4 |
1001.9 |
1015.6 |
| 8. Head Angle |
71 |
71.5 |
72.2 |
72.8 |
73 |
73.2 |
73.2 |
| 9. Seat Angle |
74.5 |
74 |
73.7 |
73.5 |
73.5 |
73.2 |
73.2 |
| 10. Standover |
736.5 |
748.5 |
767.5 |
788.5 |
808.5 |
826.5 |
852.5 |
| 11. Reach |
370 |
375 |
380 |
385 |
391 |
398 |
404 |
| 12. Stack |
506 |
515 |
533 |
552 |
572 |
590 |
616 |
| 13. Fork Length |
365 |
365 |
365 |
365 |
365 |
365 |
365 |
| 14. Rake |
48 |
48 |
48 |
43 |
43 |
43 |
43 |
| 15. Trail |
66.0 |
62.8 |
58.4 |
59.9 |
58.7 |
57.4 |
57.4 |
