Specifications

• Electric: Yes
• Fork Type: Raleigh Steel Trekking Fork For E Bike
• Frame Material: Alloy Frame AL6061
• Frame Shape: Low step
• Headset: Threaded 1" 1/8th Black
• Total Bike Weight: 20kg
• Battery: TranzX 250wh 36V 6.8Ah Battery
• Battery Charging Time: 4 hours
• Battery Integration: External
• Battery Watts per Hour: 250Wh
• Display: TranzX DP15 PST Display, 3 Assist Levels With Walk Function
• Max Range: 30 miles
• Motor: New TranzX F15 36v 250w Brushless Quick Stop Motor
• Motor Position: Rear
• Grips: Velo Comfort Grips
• Handlebar: Raleigh 560mm Straight Bar Black
• Saddle: Raleigh Ebike Saddle
• Seatpost: Alloy Micro Adjust 33.9 X 460mm
• Seatpost Clamp: 40.8 Clamp
• Stem: Folding Alloy Stem
• Front Brake: Alloy V-Brake
• Number of Gears: 7
• Rear Brake: Alloy V-Brake
• Bottom Bracket: 124.5mm Square Taper
• Cassette: 7 speed 14-34T freewheel
• Chain: KMC 1/2" x 3/32" 6/7/8 Speed
• Crankset: 48th Alloy Black With Alloy Chain-guide
• Drivetrain: Chain
• Front Shifter: Shimano Revoshift 7 Speed
• Gear Shift: Derailleur Gear
• Pedals: Folding Pedals With Anti Slip
• Rear Derailleur: Altus 7/8 Speed
• Front Wheel Hub: Alloy 36 Hole Black
• Inner Tubes: 20 X 1.95 Presta
• Rear Wheel Hub: TranzX R15 Motor
• Rim: Double Wall Rim 36 Hole 20"
• Tyres: Kenda K841 20 x 1.95 Reflective Side Wall
• Wheel Set: Double Wall Rim 36 Hole 20" On R15 Motor HubDouble Wall Rim 36 Hole 20" On Alloy Hub
• Front Light: Front Light Powered By TranzX System
• Mudguards: Matt Black Thermoplastic
• Rear Carrier: Integrated Alloy Carrier
• Rear Light: Rear Light Powered By TranzX System
• Weight Limits (Rider and Cargo): 110 KG
